Dimensions: 140 x 170 x 165(H) mm
Materials: Pure Copper, Pure Aluminum
Weight: 1,300g
Heat Dissipation Area: 15,242㎤
Heat Pipes: 6
TDP: 300W
Fan Specifications:
- Dimensions: 140 x 140 x 26(H) mm
- Bearing Type: FDB (Fluid Dynamic Bearing)
- Speed: 800~1,500 RPM ± 10%
- Max. Noise Level: 29.0 dB(A) ± 10%
- Max. Air Flow: 61 CFM
- Max. Air Pressure: 1.1 mm H₂O
- Life Span: 100,000 hours
- Connector Type:
- Fan: 4-Pin PWM
- LED: 3-Pin Addressable
- Control Method: PWM Control
- Rated Voltage:
- Fan: 12V
- LED: 5V
- Rated Current:
- Fan: 0.28A
- LED: 0.3A
- Power Consumption:
- Fan: 3.36W
- LED: 1.5W
Socket Compatibility:
- Intel: LGA 1700 / 2066 / 2011-V3 / 2011 / 1200 / 115X CPUs (ZM-1700MKA bracket required for LGA1700 compatibility)
- AMD: AM5 / AM4 / AM3+ / AM3 CPUs (ZM-AM5MKA bracket required for AM5 compatibility)
