Silverstone Gaming ET650-G 650W V1.2 ATX 80plus Gold PSU

$139.00 NZD
Tax included.
In stock!

Product description

Get ready to power up your gaming experience with the Silverstone Gaming ET650-G 650W V1.2 ATX 80plus Gold PSU! With its 650W output, single +12V rails, and 18dBA silent fan, you can enjoy maximum efficiency and performance. Plus, its 80Plus Gold certification and flat fixed cables make this PSU a sleek and reliable choice. Game on!

View Full Details
Add to Cart
Technical Specifications

Model Number

  • Product No.: SST-ET650-G

Power Specifications

  • Max. DC Output: 650W
  • Combined +3.3V & +5V: 110W
  • Combined +12V: 636W
  • Power Density: 360W per liter

Load Range

  • Output:
  • +3.3V: Max. 20A, Peak / Min. 0A
  • +5V: Max. 20A, Peak / Min. 0A
  • +12V: Max. 53A, Peak / Min. 0A
  • +5VSB: Max. 2.5A, Peak 3.0A / Min. 0A
  • -12V: Max. 0.3A, Peak / Min. 0A
  • Range (%): ±5% for +3.3V, +5V, +5VSB; ±10% for -12V
  • Line Regulation (%): ±1% for all voltages
  • Ripple (mVp-p):
  • +3.3V: 50mV
  • +5V: 50mV
  • +12V: 120mV
  • +5VSB: 50mV
  • -12V: 120mV

Input Specifications

  • Input Voltage: 90 ~ 264 Vrms
  • Input Frequency Range: 47Hz ~ 63Hz

Efficiency and PFC

  • Efficiency: 87% ~ 90% at 20% ~ 100% loading
  • PFC: Active PFC (PF > 0.9 at full load)

MTBF and Operating Conditions

  • MTBF: 100,000 hours
  • Operating Temperature: 0°C ~ 40°C

Protection Features

  • Over Current Protection
  • Over Power Protection
  • Over Voltage Protection
  • Short Circuit Protection
  • Over Temperature Protection

Connectors

  • 1 x 24 / 20-Pin Motherboard Connector: 500 mm
  • 1 x 8-Pin EPS and 1 x 4-Pin + 4-Pin ATX 12V Connector: 750 mm / 150 mm
  • 4 x 8 / 6-Pin PCIe Connectors: 500 mm / 150 mm x 2
  • 8 x SATA Connectors: 500 mm / 150 mm x 2
  • 3 x 4-Pin Peripheral Connectors: 500 mm / 150 mm x 2
  • 1 x 4-Pin Floppy Connector: 500 mm / 150 mm x 2

Cooling and Form Factor

  • Cooling System: Single 120mm silent fan
  • Form Factor: ATX

Noise Level

  • Noise Level: 18 dBA minimum

Dimensions and Weight

  • Dimensions: 150 mm (W) x 86 mm (H) x 140 mm (D)
  • Weight: 1.64 kg

Certification

  • Certification: 80 PLUS Gold
