Intel Core i7-14700 20C/28T (8P+12E Core) CPU LGA1700

$679.00 NZD
Tax included.
In stock!

Product description

Introducing the Intel Core i7-14700 20C/28T (8P+12E Core) CPU LGA1700. Featuring the latest Raptor Lake technology, enjoy an impressive 20 cores and 28 threads (8 physical and 12 emulated) for ultimate processing power. With a 2.1 up to 5.4Ghz clock speed and 33MB cache, experience seamless performance with a 65W TDP and max turbo of 219W.

View Full Details
Add to Cart
Technical Specifications

CPU Specifications

  • Total Cores: 20
  • # of Performance-cores: 8
  • # of Efficient-cores: 12
  • Total Threads: 28
  • Max Turbo Frequency: 5.4 GHz
  • Intel® Turbo Boost Max Technology 3.0 Frequency: 5.4 GHz
  • Performance-core Max Turbo Frequency: 5.3 GHz
  • Efficient-core Max Turbo Frequency: 4.2 GHz
  • Performance-core Base Frequency: 2.1 GHz
  • Efficient-core Base Frequency: 1.5 GHz
  • Cache: 33 MB Intel® Smart Cache
  • Total L2 Cache: 28 MB
  • Processor Base Power: 65 W
  • Maximum Turbo Power: 219 W

Supplemental Information

  • Marketing Status: Launched
  • Launch Date: Q1'24
  • Embedded Options Available: Yes
  • Use Conditions: PC/Client/Tablet, Workstation

Memory Specifications

  • Max Memory Size (dependent on memory type): 192 GB
  • Memory Types:
  • Up to DDR5 5600 MT/s
  • Up to DDR4 3200 MT/s
  • Max # of Memory Channels: 2
  • Max Memory Bandwidth: 89.6 GB/s
  • ECC Memory Supported: Yes

GPU Specifications

  • GPU Name: Intel® UHD Graphics 770
  • Graphics Base Frequency: 300 MHz
  • Graphics Max Dynamic Frequency: 1.6 GHz
  • Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1
  • Execution Units: 32
  • Max Resolution (HDMI): 4096 x 2160 @ 60Hz
  • Max Resolution (DP): 7680 x 4320 @ 60Hz
  • Max Resolution (eDP - Integrated Flat Panel): 5120 x 3200 @ 120Hz
  • DirectX Support:* 12
  • OpenGL Support:* 4.5
  • OpenCL Support:* 3.0
  • Multi-Format Codec Engines: 2
  • Intel® Quick Sync Video: Yes
  • Intel® Clear Video HD Technology: Yes
  • # of Displays Supported: 4
  • Device ID: 0xA780

Expansion Options

  • Direct Media Interface (DMI) Revision: 4.0
  • Max # of DMI Lanes: 8
  • Scalability: 1S Only
  • PCI Express Revision: 5.0 and 4.0
  • PCI Express Configurations: Up to 1x16+4, 2x8+4
  • Max # of PCI Express Lanes: 20

Package Specifications

  • Sockets Supported: FCLGA1700
  • Max CPU Configuration: 1
  • Thermal Solution Specification: PCG 2020C
  • TJUNCTION: 100°C
  • Package Size: 45.0 mm x 37.5 mm
  • Max Operating Temperature: 100 °C
